LG CreateBoard 86TR3DK-B
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
LG CreateBoard 86TR3DK-B
- 86" Diagonal Class TR3DK Series LED-backlit LCD display
- education / business
- with touchscreen (multi touch)
- Android
- 4K UHD (2160p) 3840 x 2160
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | 86TR3DK-B.YUSQ |
| SHI Part #: | 48259056 |
| Category: | Flat panel displays |
| UNSPSC: | 43211902 |
| Manufacturer: | LG Electronics |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Flat panel displays |
| Description | LG CreateBoard 86TR3DK-B - 86" Diagonal Class TR3DK Series LED-backlit LCD display - education / business - with touchscreen (multi touch) - Android - 4K UHD (2160p) 3840 x 2160 |
| Manufacturer | LG Electronics |
| UNSPSC | 43211902 |
| Main Specifications | |
| Dimensions & Weight / Depth | 10 cm |
| Dimensions & Weight / Height | 116 cm |
| Dimensions & Weight / Weight | 58.6 kg |
| Dimensions & Weight / Width | 195.7 cm |
| Display / Diagonal Size | 86 in |
| Header / Brand | LG |
| Miscellaneous / Product Color | Black |
| Television / Brightness | 400 cd/m² |
| Television / Combined with | Touchscreen (multi touch) |
| Television / Diagonal Size | 86 in |
| Television / Diagonal Size (cm) | 218 cm |
| Television / Display Format | 4K UHD (2160p) |
| Television / Image Aspect Ratio | 16:9 |
| Television / Image Contrast Ratio | 1200:1 |
| Television / PC Interface | VGA (HD-15) |
| Television / Resolution | 3840 x 2160 |
| Television / Type | LED-backlit LCD flat panel display |
| Television / Viewing Angle | 178° |
| Audio System | |
| Output Power / Total | 30 Watt |
| Speaker System | 2 speakers |
| Speakers | 2 x speaker - 15 Watt |
| Connections | |
| Connector Type |
|
| Dimensions & Weight (Shipping) | |
| Depth (Shipping) | 22.5 cm |
| Height (Shipping) | 128.3 cm |
| Weight (Shipping) | 75.9 kg |
| Width (Shipping) | 211 cm |
| Display | |
| Additional Features | Infrared multitouch technology, OPS Slot |
| Backlight Life | 30,000 hour(s) |
| Brightness | 400 cd/m² |
| Commercial Features | Lock Mode, Secure Mode, LG ConnectedCare DMS, LG CreateBoard Lab, Note 2.0, LG CreateBoard Share, OfficeSuite, Smart Viewing, auto-remove files |
| Display Format | 4K UHD (2160p) |
| Dynamic Contrast Ratio | 5000:1 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Image Aspect Ratio | 16:9 |
| Image Contrast Ratio | 1200:1 |
| LCD Backlight Technology | LED backlight |
| LCD Display Technology | IPS |
| Operation Hours / Days | 16 / 7 |
| Resolution | 3840 x 2160 |
| Response Time | 8 ms |
| Touchpoints Qty | 40 |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% RH |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| General | |
| Combined With | Touchscreen (multi touch) |
| Commercial Use | Yes - education / business |
| Depth | 10 cm |
| Diagonal Class | 86" |
| Dimensions | Without stand |
| HDMI Ports Qty | 3 ports |
| Height | 116 cm |
| Operating System | Android OS 11 |
| PC Interface | VGA (HD-15) |
| Platform | Android |
| Power Consumption (Max) | 580 Watt |
| Power Consumption Operational | 385 Watt |
| Product Type | LED-backlit LCD flat panel display |
| Series | TR3DK Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI, USB-C |
| Weight | 58.6 kg |
| Width | 195.7 cm |
| Media Player | |
| Configuration | ARM Cortex-A55 Quad-Core - 4 GB - 32 GB - Mali-G52 MP2 |
| USB Port | Yes |
| Network & Internet Multimedia | |
| Bluetooth Version | Bluetooth 5.0 |
| Connect & Share | Screen Share |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| LAN Protocol | Gigabit Ethernet |
| Wi-Fi Protocol | 802.11b, 802.11g, 802.11n, 802.11a, 802.11ac, 802.11ax |
| Power | |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Power Device | Power supply |
| Stands & Mounts | |
| Flat Panel Mount Interface | 800 x 600 mm |
| VESA Compatibility | Yes |
