Eaton Tripp Lite Series
MSRP$1,300.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Eaton Tripp Lite Series
- Fiber media converter
- 10GbE
- 1000Base-FX, 1000Base-TX
- SFP+ / SFP+
- up to 80 km
- 1310 / 1550 nm
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $1,300.00 |
| Mfr Part #: | N786-MDC-SFPSFP |
| SHI Part #: | 50616647 |
| Category: | Transceivers |
| UNSPSC: | 43201553 |
| Manufacturer: | Eaton |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Transceivers |
| Description | Eaton Tripp Lite Series - Fiber media converter - 10GbE - 1000Base-FX, 1000Base-TX - SFP+ / SFP+ - up to 80 km - 1310 / 1550 nm |
| Manufacturer | Eaton |
| MSRP | $1,300.00 |
| UNSPSC | 43201553 |
| Main Specifications | |
| Dimensions & Weight / Depth | 10.92 cm |
| Dimensions & Weight / Height | 2.34 cm |
| Dimensions & Weight / Weight | 850 g |
| Dimensions & Weight / Width | 7.38 cm |
| Header / Brand | Tripp Lite |
| Networking / Connectivity Technology | Wired |
| Networking / Data Link Protocol |
|
| Networking / Data Transfer Rate | 10 Gbps |
| Networking / Form Factor | Desktop |
| Networking / Type | Fiber media converter |
| Packaged Quantity | 1 |
| Service & Support / Type | 2-year warranty |
| Dimensions & Weight | |
| Depth | 10.92 cm |
| Height | 2.34 cm |
| Weight | 850 g |
| Width | 7.38 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 24 cm |
| Shipping Height | 7.5 cm |
| Shipping Width | 19 cm |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 80% RH (non-condensing) |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Interfaces | 2 x 10Gb Ethernet - SFP+ female |
| General | |
| Color | Black |
| Device Type | Fiber media converter |
| Form Factor | Desktop |
| Manufacturer Warranty | |
| Service & Support | Limited warranty |
| Miscellaneous | |
| Cables Included | 1 x power cable - 1.4 m |
| Compliant Standards | OM3, OM4, OM5, OS2, FCC, GS, LPS, TUV, UL, WEEE, CU, CAN/CSA-C22.2 No. 62368-1, FCC Part 15 Class B, IEC 62368-1, REACH, RoHS, UL 62368-1 |
| Included Accessories | 4 power plug adapters |
| Networking | |
| Cabling Type | 1000Base-FX, 1000Base-TX |
| Compliant Standards | IEEE 802.3ab, IEEE 802.3z |
| Connectivity Technology | Wired |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| Data Transfer Rate | 10 Gbps |
| Features | Single-mode, multimode, metal housing, built-in DIP switch, Digital Diagnostics Monitoring (DDM), rugged, half duplex mode, full duplex mode |
| Max Transfer Distance | 80 km |
| Optical Wave Length | 1310 / 1550 nm |
| Status Indicators | Ethernet link/activity, fiber, power, signal detect fiber |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
